150 Ton Pillar Swager Talurit
by All Lifting
Price on Application
- 150 ton pillar swager
- Die size B1 and B2 standard
- Choose between 3, 4, 5.5kW hydraulic unit
- Can be mounted on a wagon for mobile use
- Total reliability
- Economically priced
| Type | Max. Swaging Force (kN) | Max. Fluid Pressure (bar) | Length of Stroke (mm) | Type of Die | Capacity Single Stage (t) | Capacity Multi Stage (t) | Length (mm) | Width (mm) | Height (mm) | Weight (kg) |
| Swager | 1500 | 245 | 32 | B1 /B2 | 16 | 20 | 520 | 360 | 665 | 425 |
| Type | Power (kW) | Rated Current at 230/400 V (A) | Piston Velocity (mm/s) | Working Pressure (bar) | Reservoir Volume (L) | Length (mm) | Width (mm) | Height (mm) | Weight (kg) | Noise Level dB (A) |
| Hydraulic Unit | 3 | 11/6.6 | 1.8 | 0-245 | 30 | 640 | 420 | 650 | 91 | 70 |
| Hydraulic Unit | 4 | 14/8.3 | 2.8 | 0-245 | 30 | 640 | 420 | 690 | 105 | 70 |
| Hydraulic Unit | 5.5 | 22/12 | 2.7 | 40-245 | 140 | 905 | 600 | 870 | 275 | 76 |
