ALS Plus Bearing Swivels Eye and Jaw

by All Lifting
Price on Application
  • MBL is designed to be 200% of the WLL
  • Chrome plated to resist corrosion



WLL (t) Wire rope size (mm) Weight each (kgs) A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm) H (mm) I (mm) J (mm) K (mm) L (mm)
1 7 0.34 33 94 116 8 6 9 11 14 8 9 11 22
2 10 0.87 41 106 138 13 7 13 17 20 13 17 16 35
3 12.7 2.12 50 157 206 19 9 19 24 30 19 23 25 50
5 16 4.18 64 200 259 25 13 22 29 39 25 32 30 67
8.5 20 7.18 76 240 311 39 14 30 34 53 32 36 38 80
10 22.4 17.94 101 359 440 44 20 38 44 89 50 41 46 119
15 25.4 18.4 101 351 440 44 20 38 44 89 50 50 54 119
25 32 34.5 127 404 527 50 29 50 60 94 57 59 60 133
35 38 54 127 404 527 50 29 50 60 94 57 59 60 133
