Commercial Snap Hook
by All Lifting
$0.80
- Used as a temporary way to connect commercial products, and as a light duty hanging device
- Manufactured with low carbon steel
- Sizes available from 4mm to 15mm
- Key hole shaped with a spring catch
- Zinc plated finish
Safety Note: NOT FOR LIFTING APPLICATIONS.
| Part # | Size (mm) | B (mm) | E (mm) | H (mm) | |
| 14SN04 | 4 | 7 | 7 | 40 | |
| 14SN05 | 5 | 8 | 7 | 50 | |
| 14SN06 | 6 | 9 | 8 | 60 | |
| 14SN08 | 8 | 12 | 9 | 80 | |
| 14SN10 | 10 | 15 | 11 | 100 | |
| 14SN12 | 12 | 20 | 19 | 140 | |
| 14SN15 | $ | 15 | 22 | 35 | 200 |
