Compact Self Dumping Bin

by All Lifting
Price on Application
Enquire
  • Designed with a low profile for confined spaces
  • Ideal for the collection of slugs from punch machines
  • Heavy duty construction
  • Working Load Limit 1000kg
  • Enamel painted over primed steel or Galvanised finish
  • Optional wheels, crane lugs, lid, drain valve and strainer

Operating Instructions: When transporting the bin to the discharge point, the forklift tines should be positioned fully under the bin to ulitise the forklift's maximum lift capacity. To tip the bin, the catch the bin on the edge of the bulk container and reverse the forklift. When the tines clear the pivot point, raising the bin will permit a complete discharge of contents.



Part # Finish Volume (m3) WLL (kg) Unit Weight (kg) Fork Pocket Size (mm) Fork Pocket Centres (mm) Length (mm) Height (mm) Width (mm) HCG (mm) VCG (mm)
1899SSD3-G Galvanised 0.20 1000 80 165 x 65 405 1185 300 710 600 100
189SSD3-PS Painted enamel 0.20 1000 80 165 x 65 405 1185 300 710 600 100
189SSD4-G Galvanised 0.30 1000 90 165 x 65 405 1245 400 710 620 150
189SSD4-PS Painted enamel 0.30 1000 90 165 x 65 405 1245 400 710 620 150
189SSD5-G Galvanised 0.40 1000 100 165 x 65 405 1300 500 710 640 200
189SSD5-PS Painted enamel 0.40 1000 100 165 x 65 405 1300 500 710 640 200
189SSD6-G Galvanised 0.50 1000 110 165 x 65 405 1360 600 710 700 250
189SSD6-PS Painted enamel 0.50 1000 110 165 x 65 405 1360 600 710 700 250
