Crane Drum Rotators

by All Lifting
Price on Application
Enquire
  • Safely lift and rotate 205 litre steel drums either overhead crane or forklift
  • 360 degree rotation of the drum is fully controlled during operation
  • Large worm drive gearbox provides automatic braking of drum during rotation
  • When operation stops the drum will lock in position preventing dangerous and uncontrolled drum movement
  • Drum is secured into the Drum Dumper attachment with a sturdy belly strap
  • Locking pin is inserted to prevent release of the catch during the tipping cycle
  • 1 tonne capacity model for heavy duty mining and manufacturing applications
  • Zinc finish



Handle Operation - Rotation is carried out via the hand wheel fitted. Drum rotation to chest height.
Chain Operation - Rotation is carried out using the hand chain (similar to a roller door). A chain bucket is supplied for storage of the hand-chain when not in use. Drum rotation up to 3m high.

button-download-brochure

*rotation centre to lifting eye



Part # Operation WLL (kg) Rotation Rotation centre* (mm) Pocket Size (mm) Weight (kg)
189CDR1000C Chain 1000 360 940 160 x 65 220
189CDR1000H Handle 1000 360 940 160 x 65 220
189DBR40C Chain 400 360 810 160 x 65 72
189DBR40H Handle 400 360 810 160 x 65 70
