DRN Drum Rotators

by All Lifting
Price on Application
Enquire
  • Designed to lift and rotate 205 litre drums 360°
  • chain belly strap with an eccentric lock holds the drum firmly in position
  • Slip on attachment that requires only the connection of a safety chain to the forklift
  • Hot Dip galvanised finish
  • Available with PBO Plastic Barrel Option

The DR-NC Drum Rotator uses a hand chain to rotate the drum via a Gearbox for controlled rotation when lifted above chest height of the operator. The DR-NH Drum Rotator uses a handle rotation via a Gearbox of the drum cradle. Which ensures minimum effort for fully controlled tipping, allowing complete emptying of the drum contents.

Both models can be coupled with the PBO Plastic Barrel Option for use with plastic drums.



Part # Operation Type WLL (kg) Drum Size (L) Unit Weight (kg) Rotation ° Load Centre (mm) Pocket Size (mm) Pocket Centre (mm) HCG (mm)
189DR-NH Handle Standard 500 205 100 360 930 165 x 65 820 720
189DR-NH-PBO Handle Plastic Barrel Option 350 Various 130 360 940 165 x 65 820 720
189DR-NC Chain Standard 500 205 100 360 930 165 x 65 820 750
189DR-NC-PBO Chain Plastic Barrel Option 350 Various 130 360 940 165 x 65 820 800
