EQ Electric 3 Phase Chain Hoist Dual Speed

by All Lifting
Price on Application
  • Power Hoist 125kg – 1tonne capacity
  • Lightweight and compact aluminium body
  • Thermal protection prevents overheating
  • Push button control with emergency stop
  • Friction clutch for overload protection
  • Upper and lower limit switch
  • Long life gears, quiet operation
  • Counter hour metre for maintenance
  • Dust and water-jet proof body
  • Safety latches on top and bottom hooks
  • Nickel-plated load chain protects from corrosion
  • Meets Australian Standard AS1418.2

Industry Applications: Mining, construction, engineering, entertainment.

Options:

  1. MR2Q Motorised Trolley for easier and accurate load positioning in the work place
  2. Length of lift, pendant cable, and power supply cable other than standard
  3. Steel chain container for greater lift capacity



Part # Capacity (kg) Model Standard Lift (m) Lift Speed (m/min) Headroom (mm) Load Chain Dia. (mm x falls) Weight (kg)
EHP47106 125 EQ001IS 3 17-2.8 420 5.6x1 30
EHP47107 250 EQ003IS 3 10-1.7 420 5.6x1 30
EHP47108 500 EQ005IS 3 7.6-1.3 440 5.6x1 32
EHP47109 1000 EQ010IS 3 7.1-1.2 490 7.1x1 42
EHP47190 125 EQ001IS 6 17-2.8 420 5.6x1 32
EHP47191 250 EQ003IS 6 10-1.7 420 5.6x1 32
EHP47192 500 EQ005IS 6 7.6-1.3 440 5.6x1 34
EHP4719 1000 EQ010IS 6 7.1-1.2 490 7.1x1 46



Part # D (mm) a (mm) b (mm) d (mm) e (mm) f (mm) g (mm) h (mm) i (mm)
EHP47106 485 417 367 203 187 298 27 137 128
EHP47107 485 417 367 203 187 298 27 137 128
EHP47108 485 417 367 203 187 298 27 137 128
EHP47109 535 433 403 245 188 332 31 154 142
EHP47190 485 417 367 203 187 298 27 137 128
EHP47191 485 417 367 203 187 298 27 137 128
EHP47192 485 417 367 203 187 298 27 137 128
EHP47193 535 433 403 245 188 332 31 154 142
