Fork Jib Arms
by All Lifting
Price on Application
- Made from tough CrMo high tensile steel
- Light weight, slow wearing
- Standard ITA carriage hooks
- Mounting class stamped on each arm
- Supplied in a range of capacities and lengths
- Meets Australian Standards AS2359.1
*Capacity (kg) at 500mm Load Centre
Safety Note: ALWAYS ensure that the rating of the fork arm is equal to, or exceeds the rated lift capacity of the forklift. The fitting of fork arms with a lower rating than the forklift truck could lead to failure, resulting in injury or death. Each fork arm is stamped on the side with the relevant information. The rating is for an individual fork arm and should be doubled to provide a total working load limit (WLL).
| Part # | Length C (mm) | Capacity (kg)* | Mounting Class | Unit Weight (kg) Pair | A (mm) | B (mm) | D (mm) | |
| 189FA15-107 | 1070 | 1500 | II | 72 | 100 | 32 | 382 | |
| 189FA25-107 | 1070 | 2500 | II | 96 | 125 | 35 | 382 | |
| 189FA25-120 | 1200 | 2500 | II | 107 | 125 | 35 | 382 | |
| 189FA30-107 | 1070 | 3000 | III | 112 | 125 | 39 | 477 | |
| 189FA30-120 | 1200 | 3000 | III | 130 | 125 | 39 | 477 | |
| 189FA45-107 | 1070 | 4500 | III | 154 | 125 | 50 | 477 | |
| 189FA45-120 | 1200 | 4500 | III | 166 | 125 | 50 | 477 |
