Designed primarily for bridging into a standard container from ground level
Most popular ramp
Can also be used for vehicle loading from a raised dock.
Self-leveling lip allows for full load capacity when on slightly uneven ground
Ramp footing folds up to allow access to the fork slippers, for transport
Painted “Safety Yellow” enamel
Product Specifications
Shipping & Handling Fees
Part Number
WLL (kg)
Unit Weight (kg)
Width (mm)
Length (mm)
Fork Pocket Size (mm)
Fork Pocket Centres (mm)
189CR8
8000
275
2200
2000
165 x 60
775
