Forklift Extension Slippers
**Tyne size must be measured to ensure correct fit before ordering**
- The slim profile extends the versatility of your forklift
- Supplied with toggle locking pins and rating plate
- Made of a high tensile grade steel
- High working load limit (WLL)
- Made to Australian Standards AS 2359.15
- Supplied with instructions
- Zinc plated finish
- Sold as a pair
**Depending on stock availability, freight from the supplier may be charged as an additional fee**
SAFETY NOTE: In accordance with AS 2359.15, slippers for general use should be no longer than 167% of the supporting tine's length. If the slippers are longer than 167%, then their usage shall be restricted to the specified application.
*Capacity @ 500mm Load Centre
|
Part # |
Length (mm) |
Capacity* (kg) |
Max. Tine Size (mm) |
Min. Tine Length (mm) |
Weight Per Pair (kg) |
HCG (mm) |
|
189FE1-16 |
1600 |
2000 |
100 x 45 |
960 |
44 |
694 |
|
189FE1-18 |
1780 |
2000 |
100 x 45 |
1068 |
50 |
783 |
|
189FE1-20 |
2000 |
2000 |
100 x 45 |
1260 |
58 |
942 |
|
189FE1-24 |
2400 |
2000 |
100 x 45 |
1440 |
66 |
1092 |
|
189FE2-16 |
1600 |
4000 |
130 x 50 |
960 |
60 |
733 |
|
189FE2-18 |
1780 |
4000 |
130 x 50 |
1068 |
66 |
833 |
|
189FE2-20 |
2000 |
4000 |
130 x 50 |
1260 |
78 |
982 |
|
189FE2-24 |
2400 |
4000 |
130 x 50 |
1440 |
88 |
1132 |
|
189FE3-18 |
1780 |
5000 |
155 x 55 |
1068 |
89 |
809 |
|
189FE3-20 |
2000 |
5000 |
155 x 55 |
1260 |
104 |
969 |
|
189FE3-24 |
2400 |
5000 |
155 x 55 |
1440 |
119 |
1118 |
|
189FE3-30 |
3000 |
5000 |
155 x 55 |
1800 |
148 |
1418 |
|
189FE4-18 |
1780 |
8000 |
160 x 65 |
1068 |
133 |
836 |
|
189FE4-20 |
2000 |
8000 |
160 x 65 |
1260 |
155 |
986 |
|
189FE4-24 |
2400 |
8000 |
160 x 65 |
1440 |
177 |
1136 |
|
189FE4-30 |
3000 |
8000 |
160 x 65 |
1800 |
221 |
1436 |
