Grade 100 Self Locking Hook Clevis Type
by All Lifting
$67.47
- Self locking style hooks allow the hook to be easily closed with one hand, it will close itself when the load is engaged
- The hook will not open until the trigger at the back is pressed
- Clevis type allows easy connection directly to the chain
- 25% higher lifting capacity then grade 80
- Sizes available 6mm - 32mm
- Designed for single and 2 leg chain and wire rope sling applications
- Conforms to AS 2321
**Please note colour and dimensions will vary depending on supplier**
|
Code |
Chain Size (mm) |
W.L.L ( Tonne) |
A (mm) |
K (mm) |
P (mm) |
T (mm) |
H (mm) |
|
02HCSL08 |
8 |
2.5 |
9 |
119 |
34 |
20 |
24 |
|
02HCSL10 |
10 |
4.0 |
11 |
142 |
44 |
26 |
30 |
|
02HCSL13 |
13 |
6.7 |
14 |
178 |
51 |
30 |
39 |
|
02HCSL16 |
16 |
10 |
18 |
213 |
60 |
36 |
49 |
|
02HCSL20 |
20 |
16 |
21 |
244 |
70 |
53 |
65 |
|
02HCSL22 |
22 |
19 |
24 |
273 |
80 |
49 |
63 |
