Hall Stockless Anchors

by All Lifting
Price on Application

The most commonly used conventional stockless ship anchor

  • Suitable for general use, ideal for sand and shale sea bed
  • Traditional design, made from cast steel
  • ISO9001: 2008 quality system certification

Applications: Marine, Construction, Fishing, and Oil Industry.



Nominal Weight (kg) A B C h h1 L L1 B1
40 557 557 430 303 67 430 303 198
60 637 637 492 347 76 492 347 227
100 760 760 590 410 90 584 410 227
125 814 814 629 443 97 629 443 290
150 866 866 665 470 103 760 470 308
180 919 919 718 500 109 710 500 327
240 1019 1019 788 552 120 790 552 361
300 1095 1095 850 595 130 844 595 388
360 1160 1160 898 630 138 898 630 412
420 1160 1160 946 660 145 946 660 434
480 1222 1222 986 690 152 988 690 454
570 1355 1355 1042 732 161 1042 732 481
660 1356 1356 1093 769 169 1096 769 506
780 1506 1506 1170 813 178 1160 813 535
900 1580 1580 1215 855 188 1220 855 560
1020 1645 1645 1268 855 188 1220 855 560
1140 1705 1705 1316 926 203 1319 926 605
1290 1778 1778 1378 891 195 1268 891 584
1440 1844_ 1844 1448 965 203 1379 965 630
1590 1906 1906 1511 1035 226 1475 1035 677
1740 1966 1966 1571 1068 234 1517 1068 698
1920 2031 2031 1602 1104 241 1568 1104 722
2100 2093 2093 1651 1120 245 1560 1120 732
2280 2150 2150 1716 1165 225 1657 1165 763
2460 2207 2207 1785 1194 262 1700 1194 784
2640 2259 2259 1843 1222 265 1730 1222 796
2850 2318 2318 1890 1253 275 1787 1253 822
3060 2374 2374 1935 1283 282 1832 1283 841
3300 2432 2432 1985 1317 288 1880 1317 862
3540 2490 2490 2032 1349 295 1926 1394 883
3780 2547 2547 2077 1376 302 1965 1376 902
4050 2610 2610 2125 1406 309 2008 1406 924
4320 2695 2695 2171 316 316 2051 1435 943
4590 2712 2712 2216 1465 332 2093 1465 962
4890 2769 2769 2263 1498 329 2135 1498 984
5000 2800 2800 2317 1510 332 2156 1510 992
5610 2899 2899 2369 1569 345 2234 1569 1031
6000 2965 2965 2422 1605 352 2284 1605 1054
6450 3037 3037 2482 1644 361 2340 1644 1080
6900 3100 3100 2538 1681 369 2393 1681 1105
7350 3100 3100 2592 1688 370 2400 1688 1109
7800 3235 3235 2644 1752 385 2493 1752 1152
8300 3363 3363 2699 1788 393 2545 1788 1176
