Heavy Duty Self Dumping Bin
by All Lifting
Price on Application
- Designed with bulk capacity for heavy waste
- Made from 5mm plate with channel reinforcement around the bin top lip
- Oversized fork pockets to suit larger Forklifts have been incorporated into the design
- The self dumping mechanism underneath the bin allows the operator to remain seated inside the forklift during the tipping cycle
- Enamel painted over primed steel finish
- Optional crane lugs and lid
*Custom sizes are available on request
| Part # | Volume (m3) | WLL (kg) | Unit Weight (kg) | Fork Pocket Size (mm) | Fork Pocket Centres (mm) | Length (mm) | Height (mm) | Width (mm) | HCG (mm) | VCG (mm) | |
| 189JSD18 | 3.20 | 3000 | 850 | 180 x 80 | 950 | 1900 | 1125 | 1910 | 900 | 500 | |
| 189JSD24 | 4.30 | 3000 | 950 | 180 x 80 | 950 | 1900 | 1125 | 2510 | 900 | 500 | |
| 189JSD30 | 5.40 | 3000 | 1050 | 180 x 80 | 950 | 1900 | 1125 | 3110 | 900 | 500 |
