Heavy Duty Tip Up Bin
by All Lifting
Price on Application
- Manufactured from 3mm plate
- Fully reinforced edges
- Ideal for heavy waste, including metal, timber and building site rubble
- The release mechanism is activated by the forklift operator pulling the pull chord from the drivers seat
- Custom built shock absorber prevents impact forces being transmitted to the forklift during emptying
- Enamel painted over primed steel or H.D. galvanised finish
Options available: Wheels, crane lugs, lid, drain valve and strainer. A hydraulic version of this bin is also available.
| Part # | Finish | Volume (m3) | WLL (kg) | Unit Weight (kg) | Fork Pocket Size (mm) | Fork Pocket Centres (mm) | Length (mm) | Height (mm) | Width (mm) | HCG (mm) | VCG (mm) | |
| 189NTU6-G | Galvanised | 0.70 | 1000 | 190 | 165 x 65 | 405 | 1420 | 1000 | 600 | 800 | 400 | |
| 189NTU6-PS | Painted enamel | 0.70 | 1000 | 190 | 165 x 65 | 405 | 1420 | 1000 | 600 | 800 | 400 | |
| 189NTU9-G | Galvanised | 1.00 | 1000 | 210 | 165 x 65 | 635 | 1420 | 1000 | 900 | 800 | 400 | |
| 189NTU9-PS | Painted enamel | 1.00 | 1000 | 210 | 165 x 65 | 635 | 1420 | 1000 | 900 | 800 | 400 | |
| 189NTU12-G | Galvanised | 1.35 | 1000 | 225 | 165 x 65 | 635 | 1420 | 1000 | 1200 | 800 | 400 | |
| 189NTU12-PS | Painted enamel | 1.35 | 1000 | 225 | 165 x 65 | 635 | 1420 | 1000 | 1200 | 800 | 400 | |
| 189NTU15-G | Galvanised | 1.70 | 1000 | 255 | 165 x 65 | 635 | 1420 | 1000 | 1500 | 800 | 400 | |
| 189NTU15-PS | Painted enamel | 1.70 | 1000 | 255 | 165 x 65 | 635 | 1420 | 1000 | 1500 | 800 | 400 | |
| 189NTU18-G | Galvanised | 2.00 | 1000 | 280 | 165 x 65 | 635 | 1420 | 1000 | 1800 | 800 | 400 | |
| 189NTU18-PS | Painted enamel | 2.00 | 1000 | 280 | 165 x 65 | 635 | 1420 | 1000 | 1800 | 800 | 400 |
