Hydraulic Reachforks

by All Lifting
Price on Application
Enquire
  • Made from  high grade steel
  • Extendable and retractable
  • Allows trucks to load/unload from one side making the operation safer and more efficient
  • Increase warehouse space up to 30% by stacking pallets double
  • Interchangeable wear resistant strips
  • Forklift requires an additional hydraulic function to operate

Optional pallet stops to prevent the reachfork from protruding through to the rear pallet.
Optional loadguards can be custom made to suit if required.



Part # Length (mm) Capacity (kg) @ 600mm Mounting Class Extension (mm) Pocket Size (mm) Lost Load (mm) Weight Pair (kg)
189RG230-1200-850 1200 3000 II 850 140 x 56 45 175
189RG230-1350-1000 1350 3000 II 1000 140 x 56 45 190
189RG435-1200-850 1200 3500 II / III 850 170 x 56 45 210
189RG435-1350-1000 1350 3500 II / III 1000 170 x 56 45 230
189RG445-1200-850 1200 4500 III 850 170 x 56 45 215
189RG445-1350-1000 1350 4500 III 1000 170 x 56 45 235
