Plaited Wire Rope
- Made from strands of high tensile wire
- Four by three sinnet construction
- Consisting of 6 right laid and 6 left laid strands plaited together
- This material exhibits a state of torsional balance under load
- True non-rotating rope, which has no torque-bias at any stage of its working life
- Flexible and abrasion resistant
- Used as a pulling in rope in power line construction
- Easy handling due to non-spin properties
Size Dia. (mm) | MBF (kN) | Mass (kg/100m) | Number of Strands | Dia. Of Strands (mm) |
10 | 61.6 | 35 | 12 | 2.3 |
13 | 88.6 | 57 | 8 | 2.7 |
13 | 88.6 | 57 | 4 | 3 |
16 | 136 | 82 | 8 | 3.3 |
16 | 136 | 82 | 4 | 3.8 |
18 | 169 | 97 | 8 | 3.7 |
18 | 169 | 97 | 4 | 4.7 |
20 | 209 | 132 | 8 | 4.1 |
20 | 209 | 132 | 4 | 4.7 |
24 | 290 | 180 | 8 | 4.9 |
24 | 290 | 180 | 4 | 5.4 |
