Self Dumping Bin

by All Lifting
Price on Application
Enquire
  • Economical solution to collecting and disposing of industrial waste
  • Collection can be carried out at the point of manufacture
  • Reinforced edging
  • Stack up to 3 bins high
  • Available in enamel painted over primed steel or galvanised finish
  • Optional wheels, crane lugs, lid, drain valve and strainer

Operating Instructions: When transporting the bin to the discharge point, the forklift tines should be positioned fully under the bin to ulitise the forklift's maximum lift capacity. To tip the bin, the catch the bin on the edge of the bulk container and reverse the forklift. When the tines clear the pivot point, raising the bin will permit a complete discharge of contents.



Part # Finish Volume (m3) WLL (kg) Unit Weight (kg) Fork Pocket Size (mm) Fork Pocket Centres (mm) Length (mm) Height (mm) Width (mm) HCG (mm) VCG (mm)
189NSD6-G Galvanised 0.70 1000 185 165 X 65 381 1425 1000 600 750 400
189NSD6-PS Painted enamel 0.70 1000 185 165 X 65 381 1425 1000 600 750 400
189NSD9-G Galvanised 1.00 1000 200 165 X 65 635 1425 1000 900 750 400
189NSD9-PS Painted enamel 1.00 1000 200 165 X 65 635 1425 1000 900 750 400
189NSD12-G Galvanised 1.35 1000 215 165 X 65 635 1425 1000 1200 750 400
189NSD12-PS Painted enamel 1.35 1000 215 165 X 65 635 1425 1000 1200 750 400
ALS9NSD15-G Galvanised 1.70 1000 240 165 X 65 635 1425 1000 1500 750 400
189NSD15-PS Painted enamel 1.70 1000 240 165 X 65 635 1425 1000 1500 750 400
189NSD18-G Galvanised 2.00 1000 260 165 X 65 635 1425 1000 1800 750 400
189NSD18-PS Painted enamel 2.00 1000 260 165 X 65 635 1425 1000 1800 750 400
