Load Cell Shackle
by All Lifting
Price on Application
- Operating Temp: -10 to +50 °C
- Accuracy: +/- 1%
- Protection: IP67 std or submersion to 30m as option
- Robust construction
- High accuracy
- Lightweight
| Capacity (t) | Resolution (t) | Weight (kg) | |
| 1 | 0.001 | 2 | |
| 3.25 | 0.005 | 2.8 | |
| 6.5 | 0.005 | 3.2 | |
| 12 | 0.01 | 8 | |
| 25 | 0.02 | 18 | |
| 55 | 0.05 | 25 | |
| 85 | 0.05 | 45 | |
| 120 | 0.1 | 85 | |
| 200 | 0.2 | 215 | |
| 300 | 0.5 | 364 | |
| 400 | 0.5 | 520 |
| Capacity (t) | A | B | C | D | E | F | H | L | N | P |
| 1 | 16.8 | 11.2 | 36.6 | 9.65 | 26.2 | 23.1 | 63 | 74.2 | 9.65 | 55 |
| 3.25 | 26.9 | 19.1 | 60.5 | 16 | 42.9 | 38.1 | 106 | 103.5 | 17.5 | 89.5 |
| 6.5 | 36.6 | 25.4 | 84 | 22.4 | 58 | 53 | 148 | 131 | 24.6 | 120 |
| 12 | 51.5 | 35.1 | 119 | 31.8 | 82.5 | 76 | 210 | 175 | 35.1 | 165 |
| 25 | 73 | 51 | 178 | 44.5 | 127 | 106 | 313 | 254 | 57 | 230 |
| 55 | 82.5 | 57 | 197 | 51 | 164 | 122 | 348 | 282 | 61 | 264 |
| 85 | 105 | 70 | 267 | 66.5 | 184 | 145 | 453 | 356 | 79 | 344 |
| 120 | 127 | 82.5 | 330 | 76 | 200 | 165 | 546 | 394 | 92 | 419 |
| 200 | 184 | 121 | 397 | 95.5 | 279 | 267 | 743 | 562 | 1152 | 521 |
| 300 | 213 | 152 | 495 | 121 | 330 | 305 | 895 | 664 | 172 | 618 |
| 400 | 210 | 178 | 572 | 165 | 330 | 356 | 1022 | 689 | 184 | 710 |
