Code |
Dia. (mm) |
A |
B |
C |
D |
|
SS-3254-06 |
24 |
42 |
43 |
11 |
6 |
|
SS-3254-08 |
35 |
66.5 |
59 |
19 |
8 |
|
SS-3254-10 |
41 |
82 |
74 |
20 |
10 |
Grade 304 stainless steel Ideal for marine applications Electropolish finish Bronze bushes Available sizes 25mm-100mm sheave dia.
Nylon sheave With becket attached Grade 304 stainless steel
Aluminium sleeve for wire rope sizes 1.5mm – 60mm Other sizes available at request
Small swivel head block Nylon sheave Available in single or double configuration 32mm sheave or 50mm sheave Grade 304 stainless steel
Small swivel head block Nylon sheave Available in single or double configuration 32mm sheave or 50mm sheave Grade 304 stainless steel
