Stainless Steel Fork Terminal
by All Lifting
$8.71
- Stainless steel fork terminal
- Removable pin
- For swage onto wire rope sizes 3mm-16mm
- Other sizes available upon request
- Grade 316 stainless steel
**Not rated for lifting purposes**
|
Code |
Wire Met |
Dia Imp |
D3 |
L1 |
L2 |
L3 |
A |
|
137803X-025 |
2.5 |
3/32” |
5 |
45 |
28 |
11.5 |
7 |
|
137803-225 |
2.5 |
3/32” |
5 |
45 |
28 |
11.5 |
7 |
|
137803-905 |
|
1/8” |
5 |
45 |
28 |
11.5 |
7 |
|
137803M-305 |
3 |
|
5 |
67 |
40 |
12 |
7 |
|
137803-03 |
|
1/8” |
6 |
65 |
32 |
13 |
8 |
|
137803M-03 |
3 |
|
6 |
65 |
32 |
13 |
8 |
|
137803M-406 |
4 |
5/32” |
6 |
73 |
45 |
15 |
8 |
|
137803-04 |
4 |
5/32” |
8 |
77 |
46 |
15 |
11 |
|
137803-05 |
|
3/16” |
9 |
87 |
51 |
15 |
11 |
|
137803M-05 |
5 |
|
9 |
87 |
51 |
18 |
11 |
|
137803-06 |
|
1/4" |
12 |
108.5 |
69 |
27 |
15 |
|
137803-06/HD |
6 |
|
12 |
120 |
76 |
27 |
15 |
|
137803M-06/HD |
6 |
|
12 |
120 |
76 |
27 |
15 |
|
137803M-06 |
6 |
|
12 |
106 |
63 |
27 |
15 |
|
137803-08 |
8 |
5/16” |
14 |
145 |
82.5 |
29 |
15 |
|
137803-0812 |
8 |
5/16” |
12 |
148 |
80.7 |
27.7 |
15 |
|
137803-10 |
|
3/8” |
16 |
150 |
91 |
37 |
20 |
|
137803M-10 |
10 |
|
16 |
150 |
91 |
37 |
20 |
|
137803-12 |
|
1/2” |
19 |
175 |
106.5 |
37 |
20 |
|
137803M-12 |
12 |
|
19 |
175 |
106.5 |
37 |
20 |
|
137803M-14 |
14 |
|
25 |
285 |
165 |
52 |
30 |
|
137803M-16 |
16 |
|
25 |
285 |
165 |
52 |
30 |
