Swivel Hoist Ring with Alloy Steel Washer

by All Lifting
$110.26
Shipping & Handling
  • Designed for lifting heavy loads
  • Hoist rings are 360 degree swivel with 180 degree pivot function
  • Rated at 100% at 90 degree angle
  • 100% magnaflux crack detection
  • Applications: Lashing or lifting point

**Non-stock item**



Part # WLL (t) Thread (mm) E (mm) A (mm) B (mm) D (mm) F (mm) G (mm) Mass (kg)
9200 1.05 12 15 65 64 15 158 105 1.7
9203 1.90 16 20 65 64 15 158 105 1.8
9205 2.15 20 25 65 64 15 158 105 1.8
9201 4.20 24 26 85 79 19 204 134 4.2
9202 7.00 30 81 100 100 25 241 160 6.7
9207 11.00 36 76 120 111 30 286 194 15.5
9208 12.50 42 95 120 111 30 286 220 16.5
