Tipping Bin
- Economical, self dumping bin suitable for most waste handling applications
- Nesting type bin which takes up minimum space for storage and transport
- Supplied standard with 4 crane lugs and upending lugs
- Fitted with drain plug and wheel brackets (wheels not supplied unless ordered)
- Zinc plated finish
Part # | Volume (m3) | WLL (kg) | Unit Weight (kg) | Fork Pocket Size (mm) | Fork Pocket Centres (mm) | Length (mm) | Height (mm) | Width (mm) | HCG (mm) | VCG (mm) | |
189CSD9-G | 0.95 | 1500 | 180 | 185 x 75 | 340 | 1570 | 1010 | 1010 | 550 | 340 | |
189CSD12-G | 1.25 | 1500 | 205 | 185 x 75 | 630 | 1570 | 1010 | 1310 | 550 | 340 | |
189CSD18-G | 1.85 | 1500 | 245 | 185 x 75 | 630 | 1570 | 1010 | 1910 | 550 | 340 |
