Wheelie Bin Lifter
by All Lifting
Price on Application
- Safely and easily lifts 240 litre plastic bins
- Secured in the cradle by a safety chain
- 1 bin option (with 180 degree rotation), or 2 bin option
- Return the bin to upright position manually or with a forklift
- Automatically locks into position once upright
- Enamel painted over primed steel finish
The FWE24 model is fitted with a robust tipping mechanism, the tipping action is carried out by pull cord operation from the forklift drivers seat. Tipping can only be carried out once locking pin is released, preventing accidental tipping.
| Part # | No. of Bins | WLL (kg) | Load Centre (mm) | Unit Weight (kg) | Pocket size (mm) | Pocket centres (mm) | HGC (mm) | VCG (mm) | |
| 189FWB24 | 2 | 500 | 600 | 100 | 185 x 65 | 700 | 690 | -20 | |
| 189FWE24 | 1 | 250 | 1000 | 80 | 185 x 65 | 840 | 650 | 80 |
