DRW Drum Rotators

by All Lifting

Price on Application

Designed to lift and rotate 205 litre drums 360°
Ideal for long reach applications
Chain belly strap with an eccentric lock holds the drum firmly in position
Slip on attachment that only requires the connection of a safety chain for a narrow carriage forklift
Hot Dip galvanised finish

The DNW-NC model features a hand chain to rotate the drum via the gearbox, for controlled rotation.
The DNW-NH model features a handle to rotate via a Gearbox of the drum cradle. This ensures minimum effort for fully controlled tipping, allowing complete emptying of the drum contents.

Product Specifications

Shipping & Handling Fees

Part #	Operation	WLL (kg)	Drum Size (L)	Unit Weight (kg)	Rotation °	Load Centre (mm)	Pocket Size (mm)	Pocket Centre (mm)	HCG (mm)
189DRW-NC	Chain	500	205	140	360	1640	165 x 65	485	1100
189DRW-NH	Handle	500	205	130	360	1640	165 x 65	485	1100
