DRW Drum Rotators
by All Lifting
Price on Application
- Designed to lift and rotate 205 litre drums 360°
- Ideal for long reach applications
- Chain belly strap with an eccentric lock holds the drum firmly in position
- Slip on attachment that only requires the connection of a safety chain for a narrow carriage forklift
- Hot Dip galvanised finish
The DNW-NC model features a hand chain to rotate the drum via the gearbox, for controlled rotation.
The DNW-NH model features a handle to rotate via a Gearbox of the drum cradle. This ensures minimum effort for fully controlled tipping, allowing complete emptying of the drum contents.
| Part # | Operation | WLL (kg) | Drum Size (L) | Unit Weight (kg) | Rotation ° | Load Centre (mm) | Pocket Size (mm) | Pocket Centre (mm) | HCG (mm) | |
| 189DRW-NC | Chain | 500 | 205 | 140 | 360 | 1640 | 165 x 65 | 485 | 1100 | |
| 189DRW-NH | Handle | 500 | 205 | 130 | 360 | 1640 | 165 x 65 | 485 | 1100 |
