Trenchless Pipe Roller Support - Adjustable

by All Lifting
Price on Application
  • Conical or Conveyor style pipe rollers
  • For applications ranging from 2″ to 72″ steel pipe
  • Pipeline rollers are designed to protect, support and guide a pipeline section during river and road crossings
  • Pipe guide rollers help minimize drag forces of pipe-pulling through horizontally drilled or bored holes
  • Various sizes available
  • Custom designs and models available at clients request

Instructions to adjust the Pipe Roller (also known as Pipeline roller) in 3 simple steps:

1. Loosen the bolts that hold the roller frames to the base frame
2. Slide the frame sideways till the arrow on the base plate aligns with the reference number that refers to the nominal bore size of the pipe you wish to launch
3. Tighten the bolts to secure the frame to the base. The rollers are now secured in the correct position to safely launch the required pipe diameter.
